Product Features
·Dimensions: 37mm×26mm with a PBT housing
·Rated operating distance: 12mm (±40%)
·Compact size for easy installation; waterproof, oil-resistant and highly resistant to harsh environments
·Rated operating distance: 12mm (±40%)
·Compact size for easy installation; waterproof, oil-resistant and highly resistant to harsh environments
Product Parameters
| model | Induction Head | GS3-H1 |
| sensor | GS3-A12P | |
| Output Type | PNP output | |
| Detection Distance | 12mm | |
| Multiple sensors are connected in series. | Supports up to 30 sensors connected in series | |
| Minimum installation distance between the two sensors | 50mm | |
| switching frequency | 50Hz | |
| repeatability precision | ≤10% | |
| supply voltage | 24V DC +15% | |
| Consumption Current | 20mA | |
| Input1 | rated voltage | 24V DC |
| rated current | 5mA | |
| output1 | Rated output voltage | 24V DC |
| maximum output current | 250mA | |
| output3 | Rated output voltage | 24V DC |
| maximum output current | 100mA | |
| environmental resistance | levels of protection | IP67 |
| ambient temperature | Temperatures range from-25°C to +70°C, without freezing. | |
| ambient humidity | 35–85% RH, no condensation | |
| antiknock characteristics | Acceleration: 500 m/s², applied five times in each direction (X, Y, Z). | |
| vibration resistance | 10 to 55 Hz, composite amplitude of 1.5 mm, with 2-hour measurements along each X, Y, and Z axis | |
| Shell Material | PBT (Polyethylene terephthalate) | |
| outline dimension | 30mm(H)*26mm(W) | |
| Product Weight | 227g | |
| accessories of a product | not have | |
Product Dimensions
Wiring Diagram
